Blue Sea 7049 200 Amp Panel Mount 187 Series Circuit Breaker [7049]

7049 200 Amp Panel Mount 187 Series Circuit Breaker Features: Combines switching and circuit protection into a single device* Clear, single lever operation "Trip Free" design cannot be held "ON" during fault current condition Waterproof Recessed mounting holes for clean appearance Large Clearance around terminal studs accecpt heavy gauge wire lugs Robust 5/16 M8 terminals provide high torque connections Large lever with vertical/horizontal orientation provides indication of trip status Ignition protected - Safe for installation aboard gasoline powered boats Specifications: Interrupt Rating - 5,000 A@12V DC, 3,000A@24V DC, 1,500A@42V DC Maximum Voltage Rating - 48 Volts DC Operating Temperature Range - -40xC to 85xC Circuit Breaker Type - Thermally responsive bi-metal blade Circuit Breaker Class - Type III - switchable/manual reset - trip free Terminal Stud Size - 5/16"-18 Terminal Stud Torque - 75 in-lb Mounting Holes - Accept #10 (M5) Screw Weight Lb (Kg) - 0.50 (0.23) Case Material - Thermoset Polyester WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer, birth defects or other reproductive harm. For more information go to P65Warnings.ca.gov . Specifications: Amperage: 200a Box Dimensions: 3"H x 5"W x 8"L WT: 0.5 lbs UPC: 632085070496

• Ships from Mutiny Marine and Outdoors LLC
• Confirm fitment, size, and compatibility before purchase
