Blue Sea 2356100 - Water Resistant 100A Busbar w/Cover [2356100]

2356100 - Water Resistant 100A Busbar with Cover Water-resistant bussing for harsh environments. Built with wing screws for toolless access. Features: Accepts a wide range of wire sizes Includes 3 wire plugs to maintain a water-resistant rating if less than 4 wires are used Nests with other water-resistant 100A common busbars and ST-Blade water resistant fuse block for space-saving wiring Ideal for positive distribution and for the collection of negative or AC ground circuits Meets ABYC/USCG insulation requirements Tin-plated copper busses and fuse clips Includes four (4) write-on circuit labels Small format standard and custom labels are available Wing-screws designed for tool-free installation of cover to meet ABYC compliance Technical Specifications: Cover - yes Maximum Voltage - 300V AC - 48V DC Terminal Stud - 1 x #10-32 Continuous Rating - 100A AC or DC Bus Material - Tin-plated Copper Mounting Holes - Accepts 1/4" (6mm) screws Terminal Screws - 4 x # 8-32 Wire Size - Input - (1) 8 AWG to 4 AWG Wire Size - Load - (4) 16 AWG to 10 AWG In the Box: 2356100 Busbar Instruction Manual *Sold as an Individual Quick Guide (pdf)

• Ships from Mutiny Marine and Outdoors LLC
• Confirm fitment, size, and compatibility before purchase
